WINSEN ZP01-MP503 Air-Quality Monitoring Module Air quality such as formaldehyde, benzene &etc

Name: WINSEN ZP01-MP503 Air-Quality Monitoring Module Air quality such as formaldehyde, benzene &etc
Brand: MicroHello
SKU: ZP01-MP503-0001
Price: 7.8 USD
Availability: InStock

SKU: ZP01-MP503-0001

0.0 (0)

0 Sold

$7.80 ~~$25.80~~

• Air quality such as formaldehyde, benzene &etc
• Working voltage: 5.0±0.1V DC
• Application:Air cleaner, fresh-air system, intelligent integrated ceiling, air quality monitor, ventilator, air-condition

Received successfully

Coupon Code

CONTINUE SHOPPING

Add to Favorites (0)

Description

Principle Introduction:
ZP01-MP503 air-quality module adopts flat surface semiconductor gas sensor. The module has very high sensitivity to volatile organic gases such as formaldehyde, benzene, carbon monoxide, ammonia, hydrogen, alcohol and smoke of cigarette, essence &etc. The module has been aging, debugged, adjusted and calibrated. So it has good consistency and high sensitivity.

Applications :
Air cleaner, fresh-air system, intelligent integrated ceiling, air quality monitor, ventilator, air-condition.

Technical parameters :

Tips:For more parameter information, please refer to the latest manual provided by salesman.

Sensor	Air quality sensor
Target Gas	formaldehyde, benzene, carbon monoxide, hydrogen,alcohol, ammonia, smoke of cigarette, essence &etc.
Physical Interface	XH2.54-4P terminal sockets
Output Data	0－3 grade pollution signal
Working Voltage	5.0±0.2V DC (No voltage reverse connect protection)
Output Data	TTL level (200ohm protected resistance inside)
Working Current	≤60mA
Warm Up Time	≤3 min
Response Time	≤20s
RecoveryTime	≤60s
OperatingTemperature	0～50℃
OperatingHumidity	≤95％RH
StorageTemperature	－20～60℃
Storage Humidity	≤60％RH
Size	24×20×15mm（L×W×H）
Weight	≤ 20g
Sensitivity Attenuator	≤1%/year
Life Span	≥5 years
