WINSEN ME4-NO2 Nitrogen Dioxide NO2 Gas Sensor 0~20ppm

SKU: ME4-NO2-0001
0.0 (0)
0 Sold
$165.00 $465.00
• Detection Gas: NO2, nitrogen dioxide
    • Detection Range: 0~20ppm
    • Application: industrial and environmental protection fields
Received successfully
Coupon Code
CONTINUE SHOPPING
Quantity:
  • WINSEN ME4-NO2 Nitrogen Dioxide NO2 Gas Sensor 0~20ppm
  • Description
Principle Introduction:
Winsen Electronics, as a professional gas sensor manufacturer, produce NO2 gas sensor, Nitrogen Dioxide sensor for industrial use, using electrochemical working principle.
ME4-NO2 nitrogen dioxide gas sensor is constant potential electrolysis type. Oxidation-reduction reaction with nitrogen dioxide and oxygen take place respectively on the working electrode and on the counter electrode. The process releases electric charge and generates current. The current is in direct proportion to the concentration of nitrogen dioxide. So the concentration of the target gas could be got by measuring the value of current.
Applications :
It is used for nitrogen dioxide detection in industrial occasions, mine and environmental protection field.
Technical parameters :

Tips:For more parameter information, please refer to the latest manual provided by salesman.

Detection Gas nitrogen dioxide(NO2)
Detection Range 0~20ppm nitrogen dioxide sensor, NO2 gas sensor
Max range 150ppm
Sensitivity (1.2±0.3)µA/ppm
Resolution 0.1ppm
Response Time(T90) <30S
Bias Voltage 10Ω(recommended)
Load Resistance 0mV
Repeatability <2﹪Output value
Stability(/month) <2﹪
Output Linearity Linear
Zero drift(-20℃~40℃) 0.2ppm
Temperature range -20℃~50℃
Humidity range 15﹪~90﹪RH
Pressure range standard atmospheric pressure±10﹪
Lifespan 2 years(in air)


Dimensions:




Reference Circuit :











Datasheet Download
