Principle Introduction:
Winsen Electronics produces F1022 micro flow sensor, adopting thermodynamic principle to detect the gas flow.
F1022 micro flow sensor adopts thermodynamic principle to detect the gas flow, and it has high accuracy and good repeatability. The built-in temperature sensor makes the product has the function of professional temperature compensation calibration. At the same time, the output is linear analog voltage which is convenient to use.
Applications :
Industrial process control
Air and environment protection
Technical parameters :
Tips:For more parameter information, please refer to the latest manual provided by salesman.
Stable1.Technical Parameters
| Model |
F1022 |
| Measuring Range① |
2、5、6、10、12、15、20 SLM② |
| |
Min |
Typical |
Max |
Unit |
| Full Scale Output |
4.90 |
5.00 |
5.10 |
V |
| Zero Output |
0.96 |
1.00 |
1.04 |
V |
| Output Impedance |
- |
200 |
- |
Ω |
| Working Voltage |
7.0 |
10.0 |
14.0 |
V |
| Working Current |
15 |
25 |
30 |
mA |
| Accuracy |
- |
±1.5 |
±2.5 |
%F.S |
| Repeatability |
- |
±0.3 |
±0.5 |
%F.S |
| Annual Drift③ |
- |
±0.1 |
±0.5 |
%F.S |
| Pressure range④ |
- |
- |
200 |
kPa |
| Response Time |
5 |
10 |
15 |
ms |
| Working Temp.⑤ |
-25 |
- |
65 |
℃ |
| Storage Temp. |
-40 |
- |
90 |
℃ |
Note:
①The measuring range within 2-20SLM is available and regular measuring ranges such as 2、5、6、10、12、15、20 SLM. Customized fee will be charged for other ranges.
②Standard-state: gas temperature is 0℃ and pressure is 101.325 kPa.
③The testing environment is room temperature and clear air.
④The pressure range of 1 MPa can be customized.
⑤The temperature compensation is for the tem. range of 0-50℃ and the compensation performance can’t be ensured beyond the temperature range.
