Hamamatsu Flame sensor (UV TRON) R9454

Name: Hamamatsu Flame sensor (UV TRON) R9454
Brand: MicroHello
SKU: Hamamatsu-006
Price: 93 USD
Availability: InStock

SKU: Hamamatsu-006

0.0 (0)

0 Sold

$93.00 ~~$189.00~~

The R9454 is the side-on type (UV light enters from the bulb side) having a similar shape to the R2868 UVtron and also offers high sensitivity and a wide field of view (directivity).

Received successfully

Coupon Code

CONTINUE SHOPPING

Add to Favorites (0)

Description

The R9454 is the side-on type (UV light enters from the bulb side) having a similar shape to the R2868 UVtron and also offers high sensitivity and a wide field of view (directivity).

Specifications

Spectral Response (Short)	185 nm
Spectral Response (Long)	260 nm
Electrode Material	Ni
Weight	1.5 g
[Maximum Rating] Supply Voltage (DC)	500 V
[Maximum Rating] Average Discharge Current	1 mA
[Maximum Rating] Peak Current	30 mA
[Maximum Rating] Operation Ambient Temperature	-40 to +125 ℃
Discharge Starting Voltage (DC)	360 V
Discharge Sustaining Voltage (DC)	300 V
Sensitivitiy Typ.	4000 min^-1
Background Max.	10 min^-1
Estimated Life	25000 h
[Recommended Operating Parameters] Supply Voltage (DC)	400±25 V
[Recommended Operating Parameters] Average Discharge Current	0.3 mA
[Recommended Operating Parameters] Quenching Time Min.	2 ms
